Method for splicing explosion-proof optical cables

Explosion-proof optical cables are spliced using certified fusion splicers within protective enclosures designed for hazardous areas, following strict safety standards to prevent ignition.

Equipment and Enclosures

Splicing in explosive atmospheres requires specialized enclosures such as the BXJ93 Fibre Optic Splice Box, which is certified for Zone 1 and Zone 2 hazardous areas. These enclosures are made from stainless or carbon steel, rated IP66 for dust and water ingress, and can accommodate up to 288 fibers. They feature configurable internal splice trays, multiple gland entries, and maintenance-friendly hinged covers to ensure safe operation without exposing personnel to hazards.

Explosion-

Proof Fusion Splicers

Certified explosion-proof fusion splicers are essential. Devices like the Aurora MiniMod or patented designs (CN201852956U) allow low-loss, stable splicing in hazardous environments. These splicers are designed to operate safely under explosive gas or dust conditions, often incorporating a fusion splicing cavity and thermal shrinkage protection.

The optical fiber enters the splicing cavity through explosion-proof connecting cavities, ensuring that any potential sparks or heat are contained.

Safety Principles

Splicing must comply with IEC 60079-28, which governs optical radiation in explosive atmospheres. The “op is” principle (inherently safe optical radiation) limits optical energy to prevent ignition, similar to intrinsic safety in electrical systems. Systems may also use the “op sh” principle, where broken fibers are detected and optical radiation is immediately switched off to prevent hazards.

Splicing Procedure

Prepare the cable: Strip the outer jacket and buffer layers in a controlled, non-sparking environment. Insert into splice box: Feed fibers through explosion-proof glands into the splice tray. Align and splice fibers: Use a certified explosion-proof fusion splicer to align and fuse fibers.

Ensure the splicer is fully enclosed and operational according to manufacturer instructions. Protect the splice: Apply thermal shrink sleeves or protective covers within the splice tray. Test and secure: Verify optical continuity and loss, then close the enclosure, ensuring all glands are tightened and the box is sealed.

Standards and CertificationIEC 60079-28: Optical radiation safety in explosive atmospheresIEC 61508 / IEC 61511: Functional safety standards for process systemsAS6479/1: Aerospace and industrial explosion-proof fiber optic splicer specificationATEX / IECEx: Certification for hazardous area equipment Following these methods ensures safe, reliable, and compliant splicing of optical cables in environments with explosive gases or dust, minimizing the risk of ignition while maintaining high-quality optical performance.
