How do multimode optical fibers transmit signals

Optical access and telecom site reference Published 07 Oct 2024

Use this reference to prepare product questions for CGWEB NETWORKS. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Multimode optical fibers transmit signals by guiding multiple light modes through a large core using total internal reflection, allowing simultaneous propagation of several light paths.

Core Principle of Signal Transmission

Multimode fibers (MMF) have a larger core diameter, typically 50–100 micrometers, compared to single-mode fibers, which allows multiple light modes to propagate simultaneously. Light entering the fiber is confined within the core due to total internal reflection, which occurs because the core has a higher refractive index than the surrounding cladding. Each mode represents a distinct path that light can take, traveling at slightly different angles and speeds.

Modes and Propagation

The multiple paths, or modes, enable MMF to carry light from sources like LEDs or VCSELs efficiently, even if the light has poor spatial coherence. These modes can be hundreds in number, depending on the fiber's core size and numerical aperture. The step-index or graded-index design of the fiber affects how modes propagate: step-index fibers have a uniform core refractive index, while graded-index fibers gradually reduce the refractive index from the center outward, which helps reduce modal dispersion.

Signal Transmission and Limitations

As light travels through the fiber, modal dispersion occurs because different modes take slightly different times to reach the receiver, which can broaden pulses and limit the maximum transmission distance and data rate. Despite this, MMF is ideal for short- to medium-distance applications, such as within buildings, campuses, or data centers, supporting data rates up to 100 Gbps over distances of 300–550 meters depending on fiber type (OM3, OM4, OM5),.

Fiber Structure

A multimode fiber consists of three main layers: Core: The light-carrying region where multiple modes propagate. Cladding: Surrounds the core with a lower refractive index to maintain total internal reflection. Coating: Provides mechanical protection and durability.

This structure ensures that light remains guided along the fiber with minimal loss, while the large core simplifies alignment and installation, making MMF cost-effective for short-range networks.

Practical Applications

Multimode fibers are widely used in enterprise networks, data centers, and campus environments due to their high capacity, reliability, and lower-cost light sources. They are also used in fiber optic spectroscopy, imaging, and high-power laser applications, where multiple light paths or high optical power are required. In summary, multimode optical fibers transmit signals by guiding multiple light modes through a large core using total internal reflection, enabling efficient short- to medium-distance data transmission while balancing cost and performance.
