Cable tray elbow blanking dimensions are standardized to match the width, height, and radius of the main tray, with typical radii ranging from 305 mm to 1220 mm and tangent lengths of 3 inches or more.

Standard Dimensions and Specifications

Tray Widths and Heights: Cable tray elbows and blanking accessories are designed to correspond to the widths of the straight tray sections. Standard widths include 150 mm (6"), 203 mm (8"), 300 mm (12"), 450 mm (18"), 600 mm (24"), 750 mm (30"), and 900 mm (36"), with heights varying depending on tray type, typically 66 mm, 90 mm, 128 mm, 137 mm, 152 mm, 160 mm, and 203 mm. Elbow Radii: Elbows are manufactured with multiple radius options to accommodate smooth cable bends.

Common radii are 305 mm, 610 mm, 915 mm, and 1220 mm, allowing for 30°, 45°, 60°, and 90° directional changes. Tangent Lengths: Fittings, including elbows, generally include a minimum tangent of 3 inches to ensure proper alignment and connection with straight tray sections. Material and Load Considerations: Elbows and blanking plates are typically made from aluminum alloy 5052-H34 or steel, matching the material of the main tray.

They are designed to maintain structural integrity and cable support, with spacing through the middle of the fitting usually 225 mm for ladder trays. Compatibility: Blanking plates are used to cover unused openings in elbows or tees, maintaining electrical continuity and safety. They are available for both ladder and perforated tray types, ensuring compatibility with the main cable tray system.

Installation Notes: When selecting elbow blanking, ensure the radius, width, and height match the existing tray, and that the blanking does not interfere with cable fill, ventilation, or load capacity. Proper alignment with side rails and rungs is critical for maintaining mechanical support and strain relief. By following these standard dimensions and specifications, cable tray elbows and blanking accessories can be safely integrated into electrical systems, ensuring compliance with NEC, NEMA, and CSA standards while providing reliable cable management.
