How to connect the grounding bolt of the distribution box

A grounding bolt is used to connect the metal enclosure of a distribution box to the main grounding system, ensuring safety and equipotential bonding. Purpose of a Grounding BoltThe grounding bolt, often marked with a PE (Protective Earth) symbol, provides a secure point to attach grounding wires from the distribution box to the building's grounding system. This ensures that the metal enclosure and all internal components are at the same electrical potential, reducing the risk of electric shock and protecting equipment from surges or faults.

Installation Guidelines

Attach the Grounding Bolt to the Box: Drill or use a pre-threaded hole on the metal enclosure and install a grounding bolt. Ensure the metal surface is clean and free of paint or corrosion to maintain good conductivity. Connect to the PE Bus: Use a copper core wire or braided soft wire to connect the grounding bolt to the PE bus inside the distribution box.

This bus collects all ground connections from internal components. Connect to the Main Grounding System: From the PE bus or mounting plate, run a grounding wire to the building's central grounding point. Wire sizing depends on local standards: in the US, a 10 AWG (5.

26 mm²) wire is typical, while in other markets, a 6 mm² wire is used. Optional Additional Grounding: For systems with multiple spindles or long tool cables, an extra ground wire may be added between the mounting plate and spindle plate to maintain total resistance below 0. 1 Ohm.

Best Practices

Equipotential Bonding: All metal parts, including threaded conduits and internal components, should be bonded to the PE bus to prevent potential differences. Resistance Testing: Ensure the total ground resistance is low, typically below 0. 1 Ohm for industrial systems, and never exceed 25 Ohms for general grounding rods.

Use Quality Materials: Use copper or copper-bonded steel for grounding bolts and wires to prevent corrosion and maintain long-term reliability. Secure Connections: Tighten bolts properly and avoid double-tapping neutrals on the grounding point to ensure a reliable path for fault currents. By following these guidelines, the grounding bolt will provide a safe, low-resistance path to earth, protecting both personnel and equipment from electrical hazards.
