Price of wiring ducts for distribution boxes

Wiring ducts for distribution boxes typically range from $5 to $50 per piece, depending on size, material, and type.

Overview of Wiring Ducts

Wiring ducts, also called cable ducts or trays, are used to organize and protect electrical wires inside distribution boxes, control panels, and machines. They come in PVC or other plastic materials, with solid or slotted walls, and often include removable covers for easy access and maintenance. Slotted ducts allow wires to exit at multiple points, while solid ducts provide more protection against dust and debris.

Mounting options include screw-mount, adhesive, or DIN rail fasteners.

Price Factors

The cost of wiring ducts depends on several factors: Material: PVC ducts are common and affordable, while specialized materials may cost more. Size: Width, height, and length affect price; larger ducts or longer runs are more expensive. Type: Slotted ducts are slightly more expensive than solid ducts due to manufacturing complexity.

Supplier and Brand: Prices vary between distributors like DigiKey, Grainger, and TME.

Typical Price Range

Small PV

C ducts (1–2 inches wide, 1–2 feet long): $5–$15 each. Medium ducts (3–4 inches wide, 2–3 feet long): $15–$30 each. Large or specialized ducts (custom sizes, heavy-duty, or slotted): $30–$50 or more per piece.

For bulk purchases, suppliers often offer discounts, and shipping costs may apply. It is recommended to measure the space behind your distribution box and select compatible duct sizes to avoid unnecessary expenses. Where to BuyDigiKey: Offers a wide selection of slotted, solid, and flexible wire ducts with same-day shipping.

Grainger: Provides PVC wiring ducts with snap-on or hinged covers for secure installation.

TM

E: Supplies wiring ducts for industrial and telecommunication applications, including skirting ducts for wall-mounted installations. By comparing sizes, materials, and suppliers, you can select wiring ducts that fit your distribution box while staying within budget.
