Cable tray support positioning holes are pre-drilled or marked points used to secure trays to structural supports, ensuring proper load distribution and compliance with standards.

Purpose of Support Positioning Holes

Support positioning holes in cable trays are designed to: Secure the tray to support elements such as wall brackets, ceiling hangers, or floor mounts. Maintain structural integrity by evenly distributing the weight of cables along the tray. Allow flexibility for adjusting tray alignment and accommodating different mounting hardware.

Typical Hole Placement and Spacing

Rung spacing for ladder-type trays is generally 150–230 mm (6–9 inches) to support cables and maintain minimum bend radius, especially for instrumentation and control cables. Support spans depend on tray type, material, and load; ladder trays often require supports every 1. 5–3 meters, while ventilated troughs may allow slightly longer spans.

Mounting holes are usually located along the side rails or flanges of the tray, allowing bolts or threaded rods to attach the tray to brackets or hangers.

Installation Considerations

Ensure alignment with structural supports to prevent sagging or uneven load distribution. Use appropriate fasteners compatible with the tray material (steel, stainless steel, or aluminum) and environmental conditions. For mesh or ventilated trays, holes may also serve as tie points for cable ties or clamps to secure cables and prevent movement.

Follow manufacturer guidelines and standards such as DIN EN 61537 and NEMA VE 1 for spacing, load capacity, and installation practices. Practical TipsPre-mark or measure support points before drilling or mounting to ensure consistent spacing. Avoid placing holes too close to bends or joints to maintain tray strength.

Consider future cable additions when positioning supports to prevent overloading or the need for reinstallation. By following these guidelines, cable tray support holes can be effectively used to create a safe, durable, and code-compliant cable management system.
