Emergency Communication Cable Tray

Optical access and telecom site reference Published 13 Sep 2024

Use this reference to prepare product questions for CGWEB NETWORKS. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Emergency communication cable trays are specialized support systems designed to safely route EVC system cabling while enabling integration with remote monitoring for operational reliability.

Overview

Emergency communication systems, such as CARE2 EVC, require robust cabling infrastructure to ensure reliable two-way communication between building occupants and emergency services or management during evacuation events. Cable trays provide a safe, organized, and accessible method to route these critical cables, supporting fire telephones, disabled refuge alarms, steward telephones, and roaming telephones.

Cable Tray Types and Materials

Cable trays suitable for emergency communication systems include: Ladder Tray: Offers excellent ventilation and easy cable access, ideal for high-density EVC cabling. Ventilated Trough Tray: Provides partial protection while allowing airflow to prevent heat buildup.

Solid-

Bottom Tray: Used where maximum protection from dust, moisture, or electromagnetic interference is required. Wire Mesh Tray: Lightweight and flexible, suitable for complex routing and retrofit installations. Materials commonly used: Aluminum: Corrosion-resistant, lightweight, and suitable for indoor and outdoor installations.

Stainless Steel (AISI 316L): High corrosion resistance, ideal for harsh or industrial environments. Galvanized Steel: Economical and durable, with protective coating against rust.

Remote Monitoring Integration

For remote monitoring, cable trays must support cabling that connects to networked EVC panels. Modern systems allow: Loop-wired networked panels: Multiple outstations connected in a loop for redundancy. Centralized monitoring: Control panels can be interfaced with SCADA or building management systems for real-time status updates.

Alarm and fault detection: Remote monitoring can detect cable faults, disconnections, or system malfunctions, ensuring rapid response during emergencies.

Installation Considerations

Maintain minimum bend radius for cables to prevent signal degradation. Ensure proper spacing between rungs (typically 150–230 mm) for instrumentation and control cables. Use solid covers in areas with dust or potential interference.

Follow manufacturer guidelines for orientation and load capacity; some installations may use “edge-wise” orientation to minimize dust accumulation. Verify compliance with local electrical codes and standards for emergency communication systems.

Best Practices

Plan cable tray routes to minimize interference with other electrical or data systems. Use modular trays to allow future expansion of EVC systems. Label and document all cable runs for maintenance and troubleshooting.

Integrate monitoring software to provide alerts for cable faults or system issues. By selecting the appropriate cable tray type, material, and installation method, and integrating with remote monitoring systems, emergency communication networks can maintain high reliability and safety in industrial or commercial facilities.
